Product name : Stainless steel 304 316 321 metal bellows hose
Item :
Price :

Details :



Stainless steel 304 316 321 metal bellows hose



The stainless steel metal bellows hose also called bellows compensator, metal expansion joint, expansion joint pipe etc, it is a compensation element. use of bellows telescopic deformation effectively, used to absorb pipeline, container size change due to reasons such as heat bilges cold shrink etc, or absorb pipeline, container axial, lateral and angular displacement, can also be used for noise reduction vibration reduction.

Metal bellows hose construction:
Corrugated bellows hose and flange or welded pipe connector fittings

Stainless steel metal bellows hose specifications:
1 Hose material: SS304, SS316, SS321
2 Hose size: DN1-1/4"-80"
3 Bellows layer: 1-3 layer bellows(Special specifications can be customized)
4 Hose type: annular bellows
5 Connect type: flange or welded pipe
6 Flange standard: ANSI, ASME, JIS, DIN, GOST, BS, Table E etc
7 Maximum working pressure: 2.5Mpa
8 Working temperature range: -200
℃ ~ +500℃
9 Fittings material: carbon steel or stainless steel
10 Total assembly length: as per your request

Metal bellows hose advantage:
Long lasting
Flexible
Corrosion resistant
Fire resistant
High physical strength
Resistant to penetration and damage
High safety factor
Excellent at temperature, pressure extremes
Stainless steel metal expansion bellows hose

Stainless steel 304 316 321 metal bellows hose application:
Water and steam pipeline, Pumps and compressors, Exhaust gases, Lube oils, Food processing, Solvents,resins and corrosive media, Fuels and gas, Tank settlement
Industries:
Cryogenics and refrigeration, Marine, Edible oil industry, Chemical industry, Medical industry, Dairy industry, Wine making industry, Steel mills, Power generation, Boiler industry, Agro-and petro-chemical, Heating and ventilation, Paper and pulp industry, etc

Welcome to contact us for more detailed information:
E-mail: info01@apdhindustrial.com
Phone WeChat WhatsAPP: +8618832752527
